Installation and Operating Guide

-14-
HOW TO ORDER REPAIR PARTS …
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the nameplate on your equipment. Next,
determine the Part Number (not the Index Number) and the Description of each part from the following appropriate illustration and list. Be sure to give
all this information.
Heater Model Number: Part Description:
Heater Serial Number: Kind of Gas:
Part Number:
(Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store. Order parts from your
local dealer or through Gas-Fired Products, Inc. Shipments of parts are contingent upon strikes, fires, and all other causes beyond our control.
REPAIR PARTS
Index
Number
MODEL
SC10T-1–LP
MODEL
SC10T-1–NG
DESCRIPTION
Propane Gas Natural Gas
PART NUMBERS
1 43574090 43574070 Burner
2 43575210 43575180 Injector
3 43597080 43597080 Screw
4 ------------------ ------------------
5 43597140 43597140 Screw
6 43584160 43584170 ODS System
7 43576100 43576110 Regulator
8 43597110 43597110 Screw
9 43590050 43590050 Connector
10 43596010 43596010 Control Valve
11 43590050 43590050 Connector
12 43585830 43585830 Tubing – Regulator to Tap
13 43585850 43585850 Tubing – Valve to Distributor T
14 43585880 ----------------- Tubing – Valve to Pilot
15 43591010 43591010 Distributor T
16 43585840 43585840 Tubing – Distributor T to First Setting
17 43585840 43585840 Tubing – Distributor T to First Setting
18 43601070 43601070 Shoulder – Thermostatic Bulb
19 43601090 43601090 Retention Clip – Thermostatic Bulb
20 43601110 43601110 Thermostatic Valve Support
21 43597160 43597160 Screw
22 43597170 43597170 Screw
23 43587050 43587050 Thermostatic Valve Rod Adaptor
24 43588010 43588010 Pin
25 43710070 43710070 Thermostatic Control Enclosure
26 43586030 43586030 Control Knob
27 43587040 43587040 Control Rod
28 43573020 43573020 Piezo Igniter
29 43573060 43573060 Contact Piezo Igniter
30 43598020 43598020 Nut M-18
31 ----------------- 43585870 Tubing – Pilot Regulator to Pilot
32 ----------------- 43585860 Tubing – Valve to Pilot Regulator
33 ------------------ 43590060 Connector
34 ----------------- 43576010 Pilot Regulator 3.5”
35 43580270 43580270 Casing
36 43578070 43578070 Deflector
37 43597040 43597040 Screw
38 43708020 43708020 Washer
39 43597150 43597150 Screw
40 43579240 43579240 Screen
41 43581110 43581110 Safety Guard
42 43756000 43756000 Retention Clip
