Dishwasher Instruction Manual SD-2224DS SD-2224DW
Read this Manual Dear Customer, Please read this manual thoroughly before use. Understanding the unit will help you use and maintain the dishwasher properly. Please keep in a safe place for future reference. Pass it on to any subsequent owner of the appliance. For your safety, the information detailed in this manual should be followed.
IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING WARNING! When using your dishwasher, follow the precautions listed below: GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance of electric current. This appliance is equipped with a cord having an equipmentgrounding conductor and a grounding plug.
PARTS IDENTIFICATION ACCESSORIES Your dishwasher comes equipped with a 'quick connect' assembly (includes inlet and drain hose). The faucet adapter must be installed on the faucet before you can connect the dishwasher. This adapter is installed on the Quick Connect. The faucet adapter is compatible with faucets inclusive of either male (outside) or female (inside) threaded faucet connections. WARNING! In order to avoid water pressure build up, please turn off the faucet after each use.
INSTALLATION Warning Attention: Electrical Shock Hazard Disconnect electrical power before installing dishwasher. The installation of the pipes and electrical equipments should be done by professionals. Failure to do so can result in death or electrical shock. Unpacking Have at least two people to move and install the dishwasher to prevent personal injuries. Remove all packaging materials: shipping tape, foam pieces, etc. before use.
Connecting the Dishwasher Faucet Adapter & Washer Your dishwasher is equipped with a Faucet Adapter (installed on the Quick Connect), Quick Connect, Drain and Inlet Hose. The faucet adapter must be installed on the faucet before connecting the dishwasher. Remove the Faucet Adatper by pulling back the locking collar on the Quick Connect; while pulling the Faucet Adapter in the opposite direction.
1. Screw the Faucet Adapter onto (or into) the faucet. Check for leaks (use Teon or plumbers tape to eliminate any leaks if necessary). 2. Connect the six-sided connection of the Drain Hose to the dishwasher’s drain port, located on back of the dishwasher cabinet. To avoid damage to threads, do not over-tighten. 3. Connect the star-shaped connection of the Inlet Hose to the dishwasher’s inlet port, located on the back of the dishwasher cabinet. Do not over-tighten. 4.
OPERATING INSTRUCTIONS IMPORTANT To get the best performance from your dishwasher, read all operating instructions.
Loading the Dishwasher A properly loaded dishwasher is key for optimal performance. Never overll the dishwasher as it can reduce the unit’s efciency. Improper placement of items can also affect the dishwasher’s performance. Position the dishes and utensils so they are secure during the wash cycle and will not be moved by sprayed water.
Cutler y Basket Flatware should be placed in the cutlery basket with handles at the bottom. Knives and other sharp utensils should be placed with handles up, but make sure the tips do not extend through the bottom. If the rack has side baskets, spoons should be loaded individually into appropriate slots. Longer utensils should be placed horizontally on the cup shelf. WARNING! Do not let any item extend through bottom.
Detergent Dispenser Use only detergent specifically made for use with dishwashers. Keep detergent fresh and dry. Do not put powder detergent into the dispenser until you are ready to wash dishes, which can get damp and not dissolve properly. The hardness of your water will affect the amount of detergent to use. With hard water, extra detergent is need to remove deposits left by excessive minerals.
Rinse Aid Dispenser The rinse aid is released during the final rinse to help remove spots and prevent film build-up on your dishes, flatware and cookware. Also improves drying by allowing water to sheet off the dishes. Your dishwasher is designed to use liquid rinse aids. ADDING RINSE AID The rinse aid dispenser is located inside the door, next to the detergent dispenser. 1. Make sure the dishwasher door is fully open. 2. Turn the dispenser cap counter-clockwise to the left arrow. Lift and remove cap. 3.
Wach Cycle Table NOTE: Program Cycle Selection Information Description of Cycle ( ) = Rinse-Aid required Detergent pre/main Running time(min) Energy (Kwh) Water (l) 14.5 For the heaviest soiled loads, such as pots,pans,casserole dishes and dishes that have been sitting with dried food on them for a while. Pre-wash Pre-wash(122°F) Wash (131°F) Wash (122°F) Rinse Rinse (154°F) Drying 18g 100 0.47 For normally soiled loads, such as pots, plates,glasses and lightly soiled pans.
Changing the Wash Program You can change the wash program if the unit just started and only ran for a short time. Otherwise, detergent may have been released and water drained. If this is the case, the detergent dispenser must be refilled. Press and hold the START/PAUSE button for three seconds or more and unit will be in stand-by state. The program can be changed at this point. NOTE: If you open the door during a wash cycle, the unit will be paused.
MAINTENANCE Filter System The filter system consists of a Coarse Filter, a Fine Filter and a Main Filter. The filter system prevents large remnants of food or other objects from getting inside the pump. C. Coarse Filter Larger items, such as pieces of bone or glass, that could block the drain are trapped in the coarse lter. To remove items caught by this lter, gently squeeze the tap on the top of the lter and lift out. B.
Cleaning the Dishwasher The control panel can be cleaned by using a slightly dampened cloth. Dry thoroughly with a soft towel. The exterior can be wiped with a towel and mild detergent solution. Wipe clean and follow with a good appliance polish wax. Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher. Cleaning the Door Use only a soft, damp cloth with warm water to clean the edge around the door.
Keeping Your Dishwasher in Shape After Ever y Wash Turn off the water supply and leave the door slightly open so moisture and odors are not trapped inside No Solvents or Abrasive Cleaners Never use abrasive cleaners or solvents to clean the dishwasher. Only use a dampened soft towel with warm water. To remove spots or stains on the interior surface, you may use a cloth dampened with water and a little white vinegar. Clean the Door Seals Food that gets trapped in the seals may cause odors to form.
TROUBLESHOOTING Review the troubleshooting guide below to resolve common issues: ISSUE Dishwasher does not start Water not pumped from dishwasher POSSIBLE CAUSE WHAT TO DO Fuse is blown or circuit breaker is tripped Replace fuse or reset circuit breaker. Remove any other appliances sharing the same circuit Power supply is not turned on Make sure dishwasher is turned on and door is closed securely.
ISSUE Dishes are not cleaned Cloudiness on glassware POSSIBLE CAUSE WHAT TO DO Dishes were not properly loaded Reload dishes properly. Selected wash cycle was not powerful enough Select a more intensive wash cycle. Not enough detergent Use more or change brand of detergent. Items are blocking the path of the spray arm Rearrange items so the spray arm can fully rotate. The lters are dirty/clogged or installed incorrectly Clean the lter and/or check installation.
Technical Information n. i 9 6 . 19 Number of place settings 6 Maximum diameter of dishware 10.5 inches Cycles 7 Unit dimension 21.65W x 19.69D x 17.24H Water pressure 0.04-1.
Your Guarantee If this product is found to be faulty as a result of faulty materials or workmanship within one year from date of purchase, it will be repaired free of charge. This guarantee is subject to the following terms: Sunpentown must be notied of the fault. Proof of purchase must be presented to Sunpentown's nominated representative. The warranty will be void if the product if modied, misused or repaired by an unauthorized person.
