Data Sheet

建 準 電 機
SUNONWEALTH
Page 3 of 14
II. SPECIFICATION
1. MECHANICAL CHARACTERISTIC
MOTOR DESIGN
Single phase, 4-poles Brushless DC motor
BEARING SYSTEM
Precise Vapo bearing system
DIMENSIONS
See Page 6
MATERIALS OF FRAME
Thermoplastic PBT of UL 94V-0
MATERIALS OF FAN BLADE
Thermoplastic PBT of UL 94V-0
DIRECTION OF ROTATION
Counter-clockwise viewed from front of fan blade
MOUNTING HOLES
Diameter 4.3 mm in 8 holes
WEIGHT
45 g
2. ELECTRIC CHARACTERISTIC
RATED VOLTAGE
24 VDC
RATED CURRENT
80 mA / Max. 92 mA
RATED POWER CONSUMPTION
1.92 WATTS / Max. 2.21 WATTS
SAFETY POWER CONSUMPTION
2.04 WATTS
OPERATING VOLTAGE RANGE
8~27.6 VDC
STARTING VOLTAGE
8 VDC (25 deg. C POWER ON/OFF)
OPERATING TEMPERATURE RANGE
-10 to + 70 deg. C
STORAGE TEMPERATURE RANGE
-40 to + 70 deg. C
2017.09.27
D.C.C.
