Data Sheet

建 準 電 機
SUNONWEALTH
Page 3 of 14
II. SPECIFICATION
1. MECHANICAL CHARACTERISTIC
MOTOR DESIGN
Single phase, 4-poles Brushless DC motor
BEARING SYSTEM
Vapo bearing system
DI
MENSIONS
See Page 6
MATERIALS OF F
RAME
Thermoplastic PBT of UL 94V-0
MATERIALS OF FAN BLADE
Thermoplastic PBT of UL 94V-0
DIRECTION OF ROTATION
Counter-clockwise viewed from front of fan blade
MOUNTING HOLES
Diameter 4.3 mm in 4 holes
WEIGHT
33 g
2. ELECTRIC CHARACTERISTIC
RATED VOLTAGE
12 VDC
RATED CURRENT
28 mA / Max. 37 mA
RATED POWER CONSUMPTION
0.34 WATTS / Max. 0.45 WATTS
SAFETY POWER CONSUMPTION
0.48 WATTS
OPERATING VOLTAGE RANGE
4.5~13.8 VDC
STARTING VOLTAGE
4.5 VDC (25 deg. C POWER ON/OFF)
OPERATING TEMPERATURE RANGE
-10 to + 70 deg. C
STORAGE TEMPERATURE RANGE
-40 to + 70 deg. C
2018.07.04
D.C.C.
