D.C.C. 2018.02.21 SUNON SPECIFICATION FOR APPROVAL CUSTOMER : DESCRIPTION : DC BRUSHLESS FAN DIMENSIONS : 60X60X20 mm MODEL : EF60202B3-0000-A99 SUNON SPEC. NO. : D06068740G-01 CUSTOMER APPROVAL NO. APPROVED BY CUSTOMER : : (AUTHORIZED) DRAWN Miru 12/12 CHECKED Cindy-huo APPROVED Smart SPEC.NO D06068740G-01 ISSUE DATE 12 .12 .2017 EDITION 0 REVISION DATE E.SPEC E11300036 建準電機工業股份有限公司 SUNONWEALTH ELECTRIC MACHINE INDUSTRY CO., LTD. NO. 30, LN. 296, XINYA RD., QIANZHEN DIST.
I. D.C.C. 2018.02.
D.C.C. 2018.02.21 II. SPECIFICATION 1. MECHANICAL CHARACTERISTIC MOTOR DESIGN Single phase, 4-poles Brushless DC motor BEARING SYSTEM Precision ball bearing system DIMENSIONS See Page 6 MATERIALS OF FRAME Thermoplastic PBT of UL 94V-0 MATERIALS OF FAN BLADE Thermoplastic PBT of UL 94V-0 DIRECTION OF ROTATION Counter-clockwise viewed from front of fan blade MOUNTING HOLES Diameter 4.3 mm in 8 holes WEIGHT 52 g 2. ELECTRIC CHARACTERISTIC RATED VOLTAGE 24 VDC RATED CURRENT 23 mA / Max.
D.C.C. 2018.02.21 3. PERFORMANCE CHARACTERISTIC RATED SPEED 3000 RPM ± 15% at rated voltage AIR FLOW 14.1 CFM STATIC PRESSURE 0.09 Inch-H2O ACOUSTIC NOISE 24.5 dB(A) AIR FLOW V.S. PRESSURE See Page 5 INSULATION CLASS UL Class A INSULATION RESISTANCE PLASTIC HOUSING (1) 10M ohm at 500 VDC between internal stator and (2) lead wire (+) DIELECTRIC STRENGTH Applied AC 500 V for one minute or AC 600 V for 2 Seconds between housing and lead wire (+) LIFE EXPECTANCY 70,000 Hours at 40 deg.
D.C.C. 2018.02.21 MODEL : EF60202B3-0000-A99 PERFORMANCE 0 0.07 0.14 0.21 CURVES 0.28 0.35 0.42 CMM Static Pressure(Inch-H2O) 0.1 2.5 0.08 2 0.06 1.5 0.04 1 0.02 0.
D.C.C. 2018.02.21 DIMENSIONS Screw Type (Pan head) Torque Machine screw Self-tapping screw Screw Spec Size Standard 3～4 Kgf-cm M4.0 JIS B1111-1974 5～6 Kgf-cm ∮5.0 JIS B1122 Type 2 Note: SUNON recommends the screw and torque as above. Please contact SUNON, if any new requirement is requested.
D.C.C. 2018.02.
III. OTHER SPECIFIED TESTING The following is a general description of certain tests that are performed on representative SUNON fans. Nothing in this document is intended to suggest that these tests are performed on every model of SUNON fan. Moreover, the descriptions that follow each test are meant only to provide a general explanation of each test. If you would like a more detailed explanation as to any test identified in this Section, SUNON can provide such an explanation upon request. 1.
IV. CHARACTERISTIC DEFINITION The following is a general description of certain tests that are performed on representative SUNON fans in order to determine the specifications of the fan. Nothing in this document is intended to suggest that these tests are performed on every model of SUNON fan. Moreover, the descriptions that follow each test are meant only to provide a general explanation of each test.
D.C.C. 2018.02.21 4. RATED SPEED Measured after continuous 10 minute operation at rated voltage in clean air ( STATIC PRESSURE=0), and at ambient temperature of 25 degrees C under shaft horizontal condition. 5. STARTING VOLTAGE Measured the voltage which enables to start the fan in the clean air (static pressure = 0 ) by switching on at the voltage under shaft horizontal condition. It is not at continuously increasing voltage adjustment. 6.
D.C.C. 2018.02.21 V. NOTE Ⅰ.SAFETY 1. DO NOT use or operate this fan in excess of the limitations set forth in this specification. SUNON is not responsible for the non-performance of this fan and/or any damages resulting from its use, if it is not used or operated in accordance with the specifications. 2. SUNON recommends adding a protection circuit to the product or application in which this fan is installed, such as a thermo-fuse, or current-fuse or thermo-protector.
II. SPECIFICATION MODIFICATION 1. SUNON offers engineering assistance on fan installation and cooling system design. 2. All changes, modifications and/or revisions to the specifications, if any, are incorporated in the attached specifications. 3. No changes, modifications and/or revisions to these specifications are effective absent agreement, by both SUNON and the customer, in writing. 4.
6. Fan guards may prevent injury during handling or installation of the fan and are available for sale with this fan. 7. Unless otherwise noted, all testing of this fan is conducted at 25°C ambient temperature and sixty-five percent (65%) relative humidity. 8. DO NOT store this fan in an environment with high humidity. This fan must be stored in accordance with the attached specifications regarding storage temperature.
D.C.C. 2018.02.21 Declaration of RoHS Control declaration of environment-related substances/materials 1. In accordance with the Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU, SUNON product have complied with law and discipline not to employ the forbidden substances, and restrict the allowable concentration of some limited substances deliberately in our components.
