SUNON SPECIFICATION FOR APPROVAL CUSTOMER : DESCRIPTION : DC BRUSHLESS FAN DIMENSIONS : 80X80X25 mm MODEL : EE80251S2-0000-999 SUNON SPEC. NO. : D08029850G-00 CUSTOMER APPROVAL NO. APPROVED BY CUSTOMER : : (AUTHORIZED) DRAWN Jeff 06/03 CHECKED Kiddy March APPROVED Jacky SPEC.NO D08029850G-00 ISSUE DATE 12. 06. 2007 EDITION 4 REVISION DATE 06. 03. 2013 E.SPEC ED80279 建準電機工業股份有限公司 SUNONWEALTH ELECTRIC MACHINE INDUSTRY CO., LTD. TEL:886-7-8135888 NO. 30, LN. 296, XINYA RD.
I.
II. SPECIFICATION 1. MECHANICAL CHARACTERISTIC MOTOR DESIGN 2 phases, 4-poles Brushless DC motor BEARING SYSTEM Lubricated sleeve bearing system DIMENSIONS See Page 6 MATERIALS OF FRAME Thermoplastic PBT of UL 94V-0 MATERIALS OF FAN BLADE Thermoplastic PBT of UL 94V-0 DIRECTION OF ROTATION Counter-clockwise viewed from front of fan blade MOUNTING HOLES Diameter 4.3 mm in 8 holes WEIGHT 75 g 2. ELECTRIC CHARACTERISTIC RATED VOLTAGE 12 VDC RATED CURRENT 120 mA / Max.
3. PERFORMANCE CHARACTERISTIC RATED SPEED 2900 RPM ± 10% at rated voltage AIR FLOW 37 CFM STATIC PRESSURE 0.15 Inch-H2O ACOUSTIC NOISE 30 dB(A) AIR FLOW V.S. PRESSURE See Page 5 INSULATION CLASS UL Class A INSULATION RESISTANCE 10M ohm at 500 VDC between internal stator and lead wire (+) PLASTIC HOUSING DIELECTRIC STRENGTH Applied AC 500 V for one minute or AC 600 V for 2 Seconds between housing and lead wire (+) LIFE EXPECTANCY 35,000 Hours at 40 deg. C, 65% humidity, 90% CL.
MODEL : EE80251S2-0000-999 PERFORMANCE CURVES STATIC PRESSURE mm-H2O Inch-H2O 6 0.20 4 12 VDC 0.10 2 0 0 15 0 0.42 建 準 電 機 SUNONWEALTH Page 5 of 14 30 0.85 CFM m3/min D.C.C. 2013.07.
DIMENSIONS 建 準 電 機 SUNONWEALTH Page 6 of 14 D.C.C. 2013.07.
LABEL BLACK WORD COLOR:PANTONE 347C 30 SUNON EE80251S2-0000-999 DC12V 1.4W BLACK WORD COLOR :SILVER ZP T UV R hein la nd Pr od u ct Safet y DATE CODE 建 準 電 機 SUNONWEALTH Page 7 of 14 D.C.C. 2013.07.
III. OTHER SPECIFIED TESTING The following is a general description of certain tests that are performed on representative SUNON fans. Nothing in this document is intended to suggest that these tests are performed on every model of SUNON fan. Moreover, the descriptions that follow each test are meant only to provide a general explanation of each test. If you would like a more detailed explanation as to any test identified in this Section, SUNON can provide such an explanation upon request. 1.
IV. CHARACTERISTIC DEFINITION The following is a general description of certain tests that are performed on representative SUNON fans in order to determine the specifications of the fan. Nothing in this document is intended to suggest that these tests are performed on every model of SUNON fan. Moreover, the descriptions that follow each test are meant only to provide a general explanation of each test.
4. RATED SPEED Measured after continuous 10 minute operation at rated voltage in clean air ( STATIC PRESSURE=0), and at ambient temperature of 25 degrees C under shaft horizontal condition. 5. STARTING VOLTAGE Measured the voltage which enables to start the fan in the clean air (static pressure = 0 ) by switching on at the voltage under shaft horizontal condition. It is not at continuously increasing voltage adjustment. 6. LOCKED ROTOR CURRENT Measured immediately after the fan blade is locked. 7.
V. NOTE Ⅰ.SAFETY 1. DO NOT use or operate this fan in excess of the limitations set forth in this specification. SUNON is not responsible for the non-performance of this fan and/or any damages resulting from its use, if it is not used or operated in accordance with the specifications. 2. SUNON recommends adding a protection circuit to the product or application in which this fan is installed, such as a thermo-fuse, or current-fuse or thermo-protector.
II. SPECIFICATION MODIFICATION 1. SUNON offers engineering assistance on fan installation and cooling system design. 2. All changes, modifications and/or revisions to the specifications, if any, are incorporated in the attached specifications. 3. No changes, modifications and/or revisions to these specifications are effective absent agreement, by both SUNON and the customer, in writing. 4.
6. Fan guards may prevent injury during handling or installation of the fan and are available for sale with this fan. 7. Unless otherwise noted, all testing of this fan is conducted at 25°C ambient temperature and sixty-five percent (65%) relative humidity. 8. DO NOT store this fan in an environment with high humidity. This fan must be stored in accordance with the attached specifications regarding storage temperature.
Declaration of RoHS Control declaration of environment-related substances/materials 1. In accordance with the Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU, SUNON product have complied with law and discipline not to employ the forbidden substances, and restrict the allowable concentration of some limited substances deliberately in our components.
