Technical Specifications
Sunnyside Corporation 3/2009
DESCRIPTION PRODUCT IMAGE SAFETY INFORMATION
2
3
0
ITEM NUMERS & SIZES
Pint Quart 1-Gallon 2.5-Gal. 5-Gal. 55-Gal.
82216 82232 822G1 822G5 82255
HAZARDOUS INGREDIENTS PRODUCT APPLICATION
Ingredient CAS# Percent
Xylenes 1330-20-7 75-90%
Ethyl Benzene 100-41-4 10-25%
PHYSICAL PROPERTIES TEST METHOD
Typical Properties Results ASTM Applied
GRAVITY, (60 ˚F)
API 30.8 D-278
SPECIFIC 0.872 D-1298
DENSITY (Lb./GAL) 7.26
DISTILLATION RANGE
E,° F
139-141
D-86
Xylol (Xylene) TECHNICAL DATA SHEET 822
SUNNYSIDE XYLOL (XYLENE)
HEALTH:
FIRE:
REACTIVITY:
Sunnyside Xylol (Xylene) is used for thinning oil based paints where specified.
It is often used with hard to thin coatings, such as anti-rust coatings and porch
and deck enamels.
Sunnyside Xylol (Xylene) is a low initial boiling point aromatic solvent. Xylene is
a clear, colorless, flammable liquid that is miscible with most common organic
solvents. Xylene meets the requirements of ASTM D843.
Page 1 of 1
DISTILLATION RANGE
E,° F
139-141
D-86
FREEZING POINT, ˚F (˚C) -31
KAURI BUTANOL (Kb) VALUE 98 D-1133
ANILINE POINT, ˚F 48 D-611
FLASH POINT, T.C.C. ˚F 81 D-56
FLAMMABLE LIMITS IN AIR, % BY VOLUME
LOWER, AT 100˚F (38˚C) 1
UPPER, AT 200˚F (93˚C) 7
AUTOIGNITION TEMPERATURE, ˚F (˚C) 810° F D-1255
COLOR, SAYBOLT +30 D-156
DOCTOR TEST NEGATIVE D-484
CORROSION, 3 HRS. @ 212 ˚F 1A D-130
NON-VOLATILES, g/100ml <0.0010 D-1353
ACIDITY NEUTRAL D-847
ALKALINITY (AS NH3, WT%) D-1614
EVAPORATION RATE Slower than ether
APPEARANCE Clear, water-white
ODOR Aromatic Odor D-1296
VAPOR PRESSURE, mm Hg @ 20 ˚C 7.2
REFRACTIVE INDEX, @ 20 ˚C 1.4949 D-1218
SULFUR CONTENT, PPM <2 D-1266
PURITY, by G.C., Wt%
WATER CONTENT, Wt% D-1364
WATER MISCIBILITY Negligible D-1722
DOT SHIPPING NAME Flammable Liquid, NOS Contains Xylene, Ethyl Benzene
DOT CLASSIFICATION Hazard Class 3
SHIPPING Wt. at 20 ˚C 7.25
V.O.C. (g/L) 871
These properties are repesentative of typical inspections. They do not
constitute product specifications. Consult MSDS sheet for additional
information.
See MSDS sheeet for additional Health, Safety, Handling and Regulatory
Information available on our website at
www.sunnysidecorp.com/msds.html
Page 1 of 1
