Replacement Part List

8 / 10
Country of Origin: China
FF H070010003 Φ8*180mm Stake 12 PCS
Hardware Pack 4
Fig.14: Insert PC board(R1) into the gazebo top, and then insert slot(H1) and PC board(R2) into the gazebo top. Use the same
method to install the PC board(R4) and PC board(R5).
Fig.15: Cover the bottom of PC boards with “F” Baffle(I1). Insert “F” Baffle ( I2) in the same way
Fig.16: Insert middle plate(Q2) into the bottom of middle beam(F) by bolt(AA) and washer(BB).
Fig.17: Insert corner plate(Q1) into the bottom of corner beam(E) by bolt(AA) and washer(BB).
