Replacement Part List

7 / 10
Country of Origin: China
BB
H050010057
M6 Flat Washer
8PCS
AA
H010110039
M6X20 Bolt
8PCS
Hardware Pack 3
Fig.9: Use bolt(AA) and washer(BB)to lock beam(E) to roof connector(M)
Fig.10: Connect piece(O) on the top of post(A),using bolt(AA)and washer(BB) to lock the bottom of corner beam(E),
post(A) and connect piece(O) together.
Fig.11: Use bolt(AA) and flat washer(BB) to lock middle beam(F) to roof connector(M).
Fig.12:Use bolt(AA) and washer(BB) to lock the middle beam(F) to the decorative groove (D1、D2)
Fig.13:Put small roof cover(L) on roo connector (M)，Assemble Hook(N) to the roof connector(M).
