User Manual

8 in 1 SOLAR PANEL HUB
MOYEU «8 EN 1» DE PANNEAUX SOLAIRES
User’s Manual
Manuel de l'utilisateur
Congratulations on your Sunforce Products solar purchase. This product is designed to the highest
technical specifications and standards. It will supply years of maintenance-free use. Please read these
instructions thoroughly prior to installation, then store in a safe place for future reference. If at any time you
are unclear about this product, or require further assistance, please do not hesitate to contact the toll-free
helpline line at 1-877-483-6756.
Specifications
o 8 Solar Inputs
o 1 Solar Output
o Handles up to 30 Amps
o Combines up to 450 Watts of solar at 12 Volts or 900 Watts at 24 Volts
Includes
o 8-1 Solar Combiner (1)
o Trailer plugs with stripped wire (4)
Installation
Connect your individual solar panel into one of the 8 available INPUT terminals. Ensure this connection is
tight. Repeat this process up to eight times.
Connect one of the included Trailer Plug wires to the indicated OUTPUT terminal. Ensure this connection is
tight.
Connect this Trailer Plug wire (OUTPUT) to your solar charge controller (not included)
