6609 1 rev. 09/26/08

Low Height ...................................................................... 6-1/4"

Raised Height ...............................................................22.375"

Length ..................................................................................61"

Chassis Width ................................................................. 7-3/4"

Chassis Width w/ Swivel Caster Bracket....................18.375"

Handle Length .............................................................. 45-3/4"

Saddle Diameter ............................................................. 5-7/8"

Shipping Weight .......................................................... 338 lbs.

SPECIFICATIONS

OWNER'S MANUAL

MODEL 6609

CAPACITY: 10 TON

HYDRAULIC SERVICE JACK

CONTENTS:

Page 1 Speciﬁcations and Features

2 Warning Information

3 Setup, Operating and Maintenance

4 Trouble Shooting and Warranty Information

5 Exploded View Drawing

6 Replacement Parts

FEATURES:

•Uniweldconstructedhydraulicassemblyforincreasedstrengthandeliminatesleaking.

 •Flashchromedramandpumppistoninhibitrust.

 •Footpumppedalforquicklyraisingtheliftarmtotheload.

 •Lockingleveron"T"handlelockshandleinthreedifferentpositions.

 •Releaseknobontopofhandleoperatesindependentofhandlelockinglever.

 •Safetyby-passandoverloadsystemspreventoverextendingramand

prevents jack from being used beyond its rated capacity.

 •Fullswivelballbearingcasterwheelswithzerkgreasettings.

 •Frontwheelsincluderollerbearings.

 •Rearkickplatehelpsturnjackwhenintightplaces.

Summary of content (10 pages)

PAGE 1
MODEL 6609 CAPACITY: 10 TON HYDRAULIC SERVICE JACK OWNER'S MANUAL CONTENTS: Page 1 2 3 4 5 6 Specifications and Features Warning Information Setup, Operating and Maintenance Trouble Shooting and Warranty Information Exploded View Drawing Replacement Parts FEATURES: • • • • • • • • • Uniweld constructed hydraulic assembly for increased strength and eliminates leaking. Flash chromed ram and pump piston inhibit rust. Foot pump pedal for quickly raising the lift arm to the load.
PAGE 2
Warning Information This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING WARNING: Indicates a hazardous situation which, if not avoided, could result in death or serious injury. IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING BEFORE USING THIS DEVICE, READ THIS MANUAL COMPLETELY AND THOROUGHLY.
PAGE 3
MODEL 6609 CAPACITY: 10 TON HYDRAULIC SERVICE JACK OWNER'S MANUAL SETUP PLEASE REFER TO THE EXPLODED VIEW DRAWING IN THIS MANUAL IN ORDER TO IDENTIFY PARTS. 1. In order to install the handle assembly item #54 in the handle socket item #32, first align the main handle tube with the largest hole in the handle socket and the lock pin rod with the smaller hole in the handle socket. 2. Make sure the lock pin rod is in the down/lock position before insertion in the handle socket.
PAGE 4
PREVENTATIVE MAINTENANCE (CONT.) 3. It should not be necessary to refill or top off the reservoir with hydraulic fluid unless there is an external leak. An external leak requires immediate repair which must be performed in a dirt-free environment by an authorized service center. IMPORTANT: In order to prevent seal damage and jack failure, never use alcohol, hydraulic brake fluid or transmission oil in the jack. 4. Every jack owner is responsible for keeping the jack labels clean and readable.
PAGE 5
MODEL 6609 CAPACITY: 10 TON HYDRAULIC SERVICE JACK Parts list and drawing 22 21 20 16 15 19 18 14 17 13 12 54 23 11 Power unit RS660955 7 5 8 25 10 9 RS660954 24 12 26 27 39 6 38 4 3 40 49 2 2 1 41 31 55 51 42 43 44 44 37 55 27 28 47 29 30 48 46 45 50 52 24 36 35 26 50 34 33 25 12 13 7 6 23 14 15 32 25 22 21 11 20 53 8 19 5 14 18 13 16 9 17 10 5 1 2 3 3A 2 4 6609 5 rev.
PAGE 6
MODEL 6609 CAPACITY: 10 TON HYDRAULIC SERVICE JACK Parts list and drawing Index No. Part No. 1 2 3 RS660903 3A RS660903A 4 5 6 7 8 RS660908 9 10 11 12 13 14 15 16 RS660916 17 RS660917 18 19 20 21 22 23 24 RS660929 25 RS550510 26 RS550509 27 28 29 30 Description Frame Washer Front wheel (incl.
PAGE 7
MODELO 6609 CAPACIDAD: 10 TONELADAS GATO DE SERVICIO HIDRÁULICO OWNER'S MANUAL CONTENIDO: Página 1 2 3 4 5 6 Especificaciones y características Información de advertencia Ensamble, operación y mantenimiento Diagnóstico de averías e información de garantía Dibujo de vista en detalle Partes de reposición CARACTERÍSTICAS: • • • • • • Montaje de construcción hidráulica de soldadura de una sola pieza para mayor resistencia y la eliminación de fugas.
PAGE 8
Información de advertencia Este símbolo indica una alerta de seguridad y se usa para advertir sobre peligro de accidentes personales. Observe toda la información de seguridad que sigue a este símbolo para evitar la posibilidad de que ocurran lesiones o muerte. PRECAUCIÓN PRECAUCIÓN: Indica una situación peligrosa que si no se evita, puede provocar la muerte o lesiones graves. IMPORTANTE: LEA ESTAS INSTRUCCIONES ANTES DE USAR EL DISPOSITIVO ANTES DE USAR ESTE DISPOSITIVO, LEA ESTE MANUAL DETENIDAMENTE.
PAGE 9
MODEL 6609 CAPACITY: 10 TON HYDRAULIC SERVICE JACK OWNER'S MANUAL MONTAJE CONSULTE POR FAVOR EL DIBUJO DE VISTA EN DETALLE EN ESTE MANUAL PARA IDENTIFICAR LAS PARTES. 1. Para poder instalar el conjunto del mango, artículo #59, en el casquillo del mango, artículo #37. Primero alinee el tubo del mango principal con el agujero más grande en el casquillo del mango y el pasador de seguridad con el agujero más pequeño en el casquillo del mango. 2.
PAGE 10
MANTENIMIENTO DE SEGURIDAD (CONT.) 2. El gato se debe lubricar en forma periódica a fin de prevenir el desgaste prematuro de sus partes. Se debe aplicar grasa de uso general en todas las articulaciones, las ruedas pivotantes y del eje delantero, el brazo elevador, los pernos pivotantes de la base de la palanca, el sistema de seguridad y las demás superficies de apoyo. 3. No debería ser necesario recargar ni llenar el receptáculo del líquido hidráulico, salvo si existen fugas.
