18 Sun StorageTek Dual 4 Gb FC Dual GbE HBA, Emulex Installation Guide • July 2008
2. If an HBA is shown as unconfigured, use the cfgadm -c configure
command to configure it.
Configuring the HBA for Hot-Plug
Operation
1. Locate the green Power LED indicator near the bottom of the HBA front panel
(see
FIGURE 2-3 for LED location).
Power LED indicator status is shown in
TABLE 2-6.
2. If the green Power indicator is not illuminated, briefly press the Attention
button near the bottom of the HBA front panel (see
FIGURE 2-3 for Attention
button location).
The green power LED will blink for approximately five seconds and then remain
on, indicating that the HBA is properly configured.
3. To cancel the operation, press the Attention button again before it stops
blinking.
TABLE 2-6 Power LED Status Definitions
LED State Meaning Removal Status
Off No power to the HBA Removal is permitted, or the HBA must be
configured
Flashing Hot-plug in process Removal of the HBA is not permitted
Solid green HBA is properly configured Removal is not permitted
