Chapter 2 Hardware Installation and Removal 17
Testing the Installation
This section contains the following topics:
■ “To Verify Proper Installation (for the Solaris OS)” on page 17
■ “To Verify Attached Storage (for the Solaris OS)” on page 17
▼ To Verify Proper Installation (for the Solaris OS)
1. Use the cfgadm command to verify proper HBA installation.
If the HBA is properly installed and connected, you will see output similar to the
following:
2. If an HBA is shown as unconfigured or disconnected, use the cfgadm -c
configure command to configure the HBA.
▼ To Verify Attached Storage (for the Solaris OS)
1. Use the cfgadm -al command to verify attached storage.
If the HBA is properly installed and storage is connected properly, you will see
output similar to the following example. In this example, one port of an HBA is
connected through a fabric switch to two ports of a disk array.
cfgadm
Ap_Id Type Receptacle Occupant Condition
c3 fc connected configured ok
c4 fc connected configured ok
pcie5 fibre/hp connected configured ok
cfgadm -al
Ap_Id Type Receptacle Occupant Condition
c3 fc-fabric connected configured unknown
c3::200600a0b816005e disk connected configured unknown
c3::200700a0b816005e disk connected configured unknown
c4 fc connected unconfigured unknown
pcie5 fibre/hp connected configured ok
