FC Dual GbE HBA, Emulex Installation Guide
Table Of Contents
- Sun StorageTek™ Dual 4 Gb FC Dual GbE HBA, Emulex Installation Guide
- Contents
- Declaration of Conformity
- Safety Agency Compliance Statements
- Safety Precautions
- Conformité aux normes de sécurité
- Mesures de sécurité
- Symboles
- Modification du matériel
- Positionnement d’un produit Sun
- Niveau de pression acoustique
- Conformité SELV
- Connexion du cordon d’alimentation
- Mise en garde relative aux batteries
- Couvercle de l'unité
- Mise en garde relative au système en rack
- Avis de conformité des appareils laser
- Périphériques CD et DVD
- Einhaltung sicherheitsbehördlicher Vorschriften
- Normativas de seguridad
- Medidas de seguridad
- Símbolos
- Modificaciones en el equipo
- Colocación de un producto Sun
- Nivel de ruido
- Cumplimiento de la normativa para instalaciones SELV
- Conexión del cable de alimentación
- Advertencia sobre las baterías
- Cubierta de la unidad del sistema
- Advertencia sobre el sistema en bastidor
- Aviso de cumplimiento de la normativa para la utilización de láser
- Dispositivos de CD y DVD
- Nordic Lithium Battery Cautions
- Nordic Power Distribution Cautions
- Nordic Grounded Socket Cautions
- Regulatory Compliance Statements
- Preface
- HBA Overview
- Hardware Installation and Removal
- HBA Software Installation
- Known Issues
- Cannot Detect the HBA on the Sun Blade T6300 System (6680542)
- The PEM Might Not Come Online on a Sun Blade T6300 or T6320 System (6683536)
- Cannot Detect the HBA Through the BIOS on the Sun Blade X8450 System (6704510)
- Cannot Verify the FCode Version of the HBA on the Sun Blade T6300 and T6320 Systems (6686545)

1
CHAPTER
1
HBA Overview
This chapter provides a basic overview of the Sun StorageTek Dual 4 Gb FC Dual
GbE HBA, Emulex (referred to as Sun StorageTek Dual 4 Gb FC Dual GbE HBA in
this document), which uses Emulex technology. This chapter also describes the
various operating systems, host platforms, storage, and infrastructure configurations
that support the HBA. This chapter contains the following topics:
■ “Kit Contents” on page 1
■ “HBA Features and Specifications” on page 1
■ “System Interoperability” on page 4
■ “Operating System and Technology Requirements” on page 3
■ “Environmental Requirements” on page 7
Kit Contents
■ Sun StorageTek Dual 4 Gb FC Dual GbE HBA
■ Accessing Documentation document (part number: 820-2299-xx)
HBA Features and Specifications
The Sun StorageTek Dual 4 Gb FC Dual GbE HBA (SG-XPCIE2FC-GBE-E-Z) consists
of a single-wide, ExpressModule™ bus expansion board. The board interfaces an
eight-lane PCI-Express bus, with four lanes supporting two Fibre Channel (FC)
optical media ports and four lanes supporting two UTP (copper) Gigabit Ethernet
ports. The two independent FC ports operate at 4 Gbit/sec and features 4/2/1
