Use and Care Manual

6. Connect the high pressure hose to the water outlet on the
washer (Fig. 5).
mWARNING! Keep hose away from sharp objects.
Bursting hoses may cause injury. Examine hoses regularly and
replace if damaged. Do not attempt to mend a damaged hose.
7. Connect the garden hose adaptor (female coupler) to the
water inlet of the pressure washer, then thread your garden
hose (male end) into the garden hose adaptor (Fig. 6). The
garden hose must have an internal diameter of at least
13 mm (1/2 in.) and must be reinforced. The water supply
must be at least equal to the washer delivery capacity.
NOTE: The machine is not suitable for connection to the
portable water main.
8. Attach garden hose to water supply (Fig. 7).
mWARNING! The intake water temperature must not
exceed 104ºF/40ºC. The water supply must not exceed
0.7 MPa.
mCAUTION! The washer must only be used with clean
water; use of unltered water containing corrosive chemicals
will damage the washer.
9. Push the motor switch to the OFF (0) position (Fig. 8).
10. Check that the electrical supply voltage and frequency
(Volt/Hz) correspond to those specied on the washer
rating plate. If the power supply is correct, you may now
plug the washer into the power outlet (Fig. 9).
Operation
m
IMPORTANT! This pressure washer is equipped with
a micro-switch sensitive to water ow. This Total Stop System
(TSS) senses water ow in the pump. When the trigger is
released, water stops owing through the pump. The TSS then
automatically turns the motor off to protect the pump from
overheating.
1. Turn the water supply tap on completely.
Fig. 5
High pressure water outlet
(REAR)
High pressure hose
Fig. 6
Water inlet
(female coupler)
(FRONT)
Garden hose
This end to
water inlet
Garden hose
(male end)
Fig. 7
Connect to water supply
Garden hose
OFF
ON
1
0
OFF
ON
Fig. 8
Fig. 9
(GFCI)
6
