3. To power on, press and hold the safety lock button while

puling the switch bar lever toward you (Fig. 15). Once the

machine powers on, release the safety lock button and

proceed with operation. The lawn mower can only be

started by pressing the safety switch button rst, followed

by squeezing the ON/OFF switch bar lever; reverse

operation will not start the machine.

4. To power o, release the ON/OFF switch bar lever

(Fig. 15).

Grass Bag Filling Level Indicator

1. The grass bag is equipped with a lling level indicator

window that is opened by the airow that the lawn mower

generates during operation (Fig. 16).

2. If the ap closes during mowing, this indicates that the

grass bag is full and must be emptied (Fig. 16).

NOTE: To ensure that the lling level indicator functions

properly, keep the holes under the ap clean and permeable.

Mowing Tips

mWARNING! Inspect the area prior to mowing and

remove all the stones, sticks, wires and other foreign objects

that could be picked up and thrown by the rotating blade.

Failure to comply not only will damage the mower blade, but

can also lead to serious personal injury.

• Be sure to check the mowing blade periodically for signs

of wear and sharpen it at least once per year, as described

in the maintenance section.

NOTE: A sharp blade will greatly enhance the

performance of the mower, especially when cutting tall

blades of grass.

• When cutting thick grass, reduce your walking speed

in order to allow for a more eective cut and a proper

discharge of the clippings. For a healthy lawn, always cut

o one-third or less from the total length of the grass. The

average lawn should be approximately 1.5 to 2 in. (3.8 to 5

cm) long during cool months, and more than 2 in. (5 cm)

long during hot months. If there is growth, the lawn should

be cut in the fall.

• The lawn will look better if it is always cut to the same

height and in alternate directions.

Fig. 14

Battery cover

Battery

Safety key

Fig. 15

Switch bar level

Safety lock button

STOP

Fig. 16

Grass indicator window
