Owner manual

DETAIL A
SCALE 1 / 10
A
CENTER3/8/2012 9LR0410.iam/
↑
↑
↑
↑
8P4211
8P7122
8X0111
3/4" X 2-1/2"
8R8005
SNAP RING
8R8010
8X0306
3/4" LW
8X0265
3/4" LN
8P5080
BLOCK FRAME
AT ARROWS
AFTER DRUM IS INSTALLED
PLACE STANDS AT THE 4
LOCATIONS SHOWN TO
STABILIZE FRAME
OF GREASE ZERK
NOTE ORIENTATION
SNAP RING IS OPTIONAL.
DUE TO MANUFACTURING TOLERANCE THE SNAP RING MAY NOT BE NEEDED.
5-2
SECTION 5 – PARTS
