Owner manual

4-2
SPECIFICATIONS
Working Transport Transport Transport Machine Roller
Width Width Height Length Weight Diameter
41’ 12’6” 6’8” 42’5” 22,880# 42”
46’ 12’6” 6’8” 45’ 24,310# 42”
53’ 12’6” 6’8” 52’5” 25,840# 42”
Tire Size Rating Recommended Ination Pressure
12.5Lx15 LRF 90 PSI
340/65R18 148A8 78 PSI
Hub Size Rating Recommended Wheel Recommended Axle
Nut Torque Nut Torque
HD812 6100 LB. 240 ft.-lbs. 45 ft.-lbs., loosen until
20 MPH Maximum rst slot is aligned with
hole in axle, install cotter
pin, bend to retain.
HD817 7500 LB. 240 ft.-lbs. 45 ft.-lbs., loosen until
20 MPH Maximum rst slot is aligned with
hole in axle, install cotter
pin, bend to retain.
STORAGE
1. Follow steps outlined in “UNHOOKING LAND ROLLER FROM TRACTOR IN FIELD POSITION”.
2. Clean and remove all excessive dirt and grease from Land Roller.
3. Grease all zerks.
4. To prevent rusting, repaint any areas that have been worn, chipped or scratched.
5. Apply grease* to any exposed part of cylinder shafts.
*NOTE: Before returning Land Roller into service, all grease must be removed from cylinder
shafts to prevent damage to seals.
SECTION 4 – MAINTENANCE
