SECTION 3 – OPERATION
3-2
INITIAL HOOKUP:
1. Make tractor to hitch connection with locking draw pin and safety chain.
2. Retract jack and rotate into storage position.
3. Plug Lockpin Cylinder hoses into desired tractor outlet, adjust hydraulic ow rate to 35% of maxi-
mum. Insure that tips and couplers are CLEAN.
4. Plug Lift Cylinder hoses into desired tractor outlet, adjust hydraulic ow rate to 35% of maxi-
mum.
5. Plug Pivot Lock Cylinder hoses into desired tractor outlet, adjust hydraulic ow rate to 35% of
maximim.
6. Connect safety Light Kit wiring harness to 7 pin receptacle.
7. If Land Roller is in Transport Position, follow “Steps Required to Unfold from Transport to Field
Position”.
8. INITIAL CHECK – with machine in Field Position
A. After receiving or assembling your Land Roller, it is a good practice to double check the entire
machine so all fasteners are securely tightened.
B. Make sure all grease ttings are in place and greased properly.
C. Inate tires to recommended ination pressure (see page 4-2), check that wheel nuts are
tightened to 240 ft-lb and check that wheel bearings are correctly adjusted.
