I. Appendix - Pin List
For detailed pin information, please see ESP8266 Pin List.
• Digital Die Pin List
• Buffer Sheet
• Register List
•
Strapping List
📖 Notes:
• INST_NAME refers to the IO_MUX REGISTER defined in eagle_soc.h, for example MTDI_U refers
to PERIPHS_IO_MUX_MTDI_U.
• Net Name refers to the pin name in schematic.
•
Function refers to the multifunction of each pin pad.
• Function number 1 ~ 5 correspond to FUNCTION 0 ~ 4 in SDK. For example, set MTDI to GPIO12
as follows.
- #define󰐇FUNC_GPIO12󰐇󰐇3󰐇//defined󰐇in󰐇eagle_soc.h
- PIN_FUNC_SELECT(PERIPHS_IO_MUX_MTDI_U,FUNC_GPIO12)
