5. Electrical Specifications
5. Electrical Specifications
5.1. Electrical Characteristics
5.2. Power Consumption
Table 5-1. Electrical Characteristics
Parameters
Conditions
Min
Typical
Max
Unit
Storage Temperature Range
-
-40
Normal
125
℃
Maximum Soldering Temperature
IPC/JEDEC J-
STD-020
-
-
260
℃
Working Voltage Value
－
2.5
3.3
3.6
V
I/O
V
IL
/V
IH
-
-0.3/0.75V
IO
-
0.25V
IO
/3.6
V
V
OL
/V
OH
-
N/0.8V
IO
-
0.1V
IO
/N
I
MAX
-
-
-
12
mA
Electrostatic Discharge (HBM)
TAMB=25℃
-
-
2
KV
Electrostatic Discharge (CDM)
TAMB=25℃
-
-
0.5
KV
Table 5-2. Power Consumption
Parameters
Min
Typical
Max
Unit
Tx802.11b, CCK 11Mbps, P OUT=+17dBm
-
170
-
mA
Tx 802.11g, OFDM 54Mbps, P OUT =+15dBm
-
140
-
mA
Tx 802.11n, MCS7, P OUT =+13dBm
-
120
-
mA
Rx 802.11b, 1024 bytes packet length , -80dBm
-
50
-
mA
Rx 802.11g, 1024 bytes packet length, -70dBm
-
56
-
mA
Rx 802.11n, 1024 bytes packet length, -65dBm
-
56
-
mA
Modem-sleep
①
-
15
-
mA
Light-sleep
②
-
0.9
-
mA
Deep-sleep
③
-
20
-
μA
Power Off
-
0.5
-
μA
