TOP
BRACKET
Bracket installation.
Clip installation.
Bracket Installation
Loosen the two screws on the top handle side of each unit.
Slide the top bracket under the four screw heads, then
tighten screws. Refer to the illustration below.
Center Trim Installation
Secure handle side trim using the four sets of clips and
screws provided. Refer to the illustration below. If using a
power drill, set to lowest torque setting to ensure screws
do not strip out inside clips.
Align center trim with clips, verify the top of the trim is
aligned with the top of the opening, then press into position.
Tall and Column Models – Dual Installation
