TECHNICAL SPECIFICATION
Stuart Turner reserve the right to amend the specification in line with it’s policy of
continuous development of its products.
*Note: Max working pressure is the maximum pressure that can be applied to the
pump internal casing under any installation conditions.
Note: For information on other voltages/frequencies which are not shown, consult
any supplementary instruction sheet supplied, or the rating label attached to
the pump.
NOISE
The equivalent continuous A-weighted sound pressure level at a distance of 1 metre
from the pump does not exceed 70 dB(A).
ENVIRONMENT PROTECTION
Your appliance contains valuable materials which can be recovered or recycled.
At the end of the products’ useful life, please leave it at an appropriate local civic waste
collection point.
Model 3.2 bar 4.7 bar
Electrical
Power supply
Volts/phase freqency
230/1/50 230/1/50
Motor enclosure IPX4 IPX4
Type of motor Induction Induction
Power consumption 880 Watts 1060 Watts
Full load current 3.9 Amps 4.9 Amps
Rating Continuous (S1) Continuous (S1)
Max. No Starts per hour 60 60
Mechanical
Max inlet head 10 metres 10 metres
Max head (closed valve) 30.5 metres 47 metres
Max working pressure* 400 kPa (4.0 bar) 600 kPa (6.0 bar)
Max ambient air temperature 40
o
C 40
o
C
Max water temperature** 35
o
C 35
o
C
Min water temperature 4
o
C4
o
C
Dimensions
Length 541 mm 530 mm
Width 275 mm 275 mm
Height (excluding flexible hoses) 665 mm 688 mm
Gross Weight (packed) 16 Kg 18 Kg
