RCC130H-CRACK SAW OPERATION AND PARTS MANUAL REV #1 (11/18/04) PAGE 51
FRAME ASSY.
FRAME ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 29022-001 FRAME, MAIN 1
2 29018-046 WHEEL 2
3 07030-012 WASHER, FLAT ¾” PLATED 2
4 07028-069 PIN, COTTER 3/16” X 2 PLATED 2
5 29022-002 BUMPER, RUBBER 2
6 08696-010 SCREW, CAP COUNTERSUNK ¼-20 UNC X 5/8” 6
7 29022-003 WHEEL, CASTER 2
8 29022-004 BEARING, PILLOW BLOCK 2
9 08233-006 NUT, HEXAGON NYLOC 3/8-16 UNC, PLATED 4
10 08233-008 NUT, HEXAGON NYLOC 1/2-13 UNC, PLATED 8
11 07030-006 WASHER, FLAT 3/8”, PLATED 4
12 07030-008 WASHER, FLAT ½” PLATED 8
13 06501-012 SCREW, CAP 3/8-16 UNC X 1-1/2”, PLATED 4
14 06503-012 SCREW, CAP ½-13 UNC X 1-3/4” PLATED GRD 5 8
23 29022-036 PAD, NON SLIP 1
24 29020-010 CAP, DUST COVER 1
