User's Manual

User guide
1.1． Description：
This product is a Bluetooth wireless optical mouse, dedicated, PS3 and PC host, the host of three
key (Left key/Middle key/Right key) with the wheel.
This product incorporates a separate baseband processors and integrated 2.4GHz transceiver,
Bluetooth 2.0. Use 2.4 G wireless data communication with PS3 console(or bluetooth adapter).Wireless
module frequency coverage：2402-2480MHz，Channel：79，data modulation mode：FSK. Antenna type：
IFA，Antenna gain：3.3dBi（Max）.
. The wireless distance may amount to 8-10 mete.
1.2． Use method：
1.2.1 Install the battery: (using the battery: 2 AAA batteries-1.5V) (picture 1)
picture 1
picture 2 picture 3
Press and hold the battery cover, remove the battery cover, according to a diagram position
packed battery, the battery cover on the cover (picture 2/3).
1.2.2 The mouse on the PS3 for use on the host:
1.2.2.1 PS3 controller and PS3 host (picture 4) line
The PS3 host and TV link good, adjust the TV video. in accordance with the PS3 host switch 级
machine press-on, led indicates a green; use PS3 controller (picture 5) control, set the PS3 controller
USB cord and PS3 host connections, by PS PS3 controller keys. using boot PS3 master operations.
Batterycove
Battery
finished
product
after
packing
Battery
cover key
Here for
two
section
battery
cathode
TwoAAA
batteries
