User Manual

DXIFS-160/RAID User's Guide - Rev. B00 StorCase Technology, Inc.
Installation 9
Figure 5B: Special InfoStation RAID Module 2x2 Dual-Channel Configuration
(Using Port B and 12m Cables)
I/O Repeater
Module #1
I/O Repeater
Module #1
Disk Ch. 2
(3 Disks)
InfoStation #4
InfoStation #3
NOTE: Maximum 15 Disks per SCSI Channel Cable length should not exceed 12m each!
I/O Repeater
Module #1
InfoStation #2
IFS_RAID24
Disk Ch. 2
(4 Disks)
To Host 0
To Host 1
I/O Repeater
Module #1
RAID Module
T T
Disk Ch. 1
(4 Disks)
InfoStation #1
T T
Disk Ch. 1
(4 Disks)
Disk Ch. 1
(4 Disks)
Disk Ch. 1
(3 Disks)
Disk Ch. 2
(4 Disks)
Disk Ch. 2
(4 Disks)
T
T
TT
T
T
I/O Repeater
Module #2
I/O Repeater
Module #2
I/O Repeater
Module #2
T
=Terminator
I/O Repeater
Module #2
