Absolute maximum ratings and operating conditions TL1431
4/18 Doc ID 5286 Rev 5
2 Absolute maximum ratings and operating conditions
Table 1. Absolute maximum ratings
Symbol Parameter Value Unit
V
KA
Cathode to anode voltage 37 V
I
k
Continuous cathode current range -100 to +150 mA
I
ref
Reference input current range -0.05 to +10 mA
T
j
Junction temperature +150 °C
P
d
Power dissipation
(1)
TO92
SO-8 batwing
1. Calculated with T
j
=+150°C and T
amb
=+25°C with relative R
thja
depending on the package.
625
960
mW
T
stg
Storage temperature range -65 to +150 °C
ESD
HBM: human body model
(2)
MM: machine model
(3)
CDM: charged device model
(4)
2. Human body model: A 100 pF capacitor is charged to the specified voltage, then discharged through a
1.5 kΩ resistor between two pins of the device. This is done for all couples of connected pin combinations
while the other pins are floating.
3. Machine model: A 200 pF capacitor is charged to the specified voltage, then discharged directly between
two pins of the device with no external series resistor (internal resistor < 5 Ω). This is done for all couples of
connected pin combinations while the other pins are floating.
4. Charged device model: all pins and the package are charged together to the specified voltage and then
discharged directly to the ground through only one pin. This is done for all pins.
2000
200
1500
V
Table 2. Operating conditions
Symbol Parameter Value Unit
V
KA
Cathode to anode voltage V
ref
to 36 V
I
k
Cathode current 1 to 100 mA
T
oper
Operating free-air temperature range
TL1431C/AC
TL1431I/AI
TL1431IY/AIY
-20 to +70
-40 to +105
-40 to +125
°C
R
thja
Thermal resistance junction to ambient
SO-8 batwing
TO92
130
200
°C/W
