STM32F105xx, STM32F107xx Application block diagrams
Doc ID 15274 Rev 6 91/104
Figure 47. Host connection
1. STMPS2141STR needed only if the application has to support bus-powered devices.
USB
OTG
Full-speed
core
STM32F105xx/STM32F107xx
USB
full-speed/
low-speed
transceiver
DP
USB Std-A connector
DM
V
BUS
V
SS
HNPHNP
SRPSRP
IDID
OTG PHY
ai15654b
GPIO
GPIO + IRQ
EN
OVRCR
flag
Current-limited
power distribution
switch
STMPS2141STR
(1)
V
DD
(2)
5 V
