STM32F105xx, STM32F107xx Pinouts and pin description
Doc ID 15274 Rev 6 29/104
G10 - 62 PD15 I/O FT PD15 TIM4_CH4
F10 37 63 PC6 I/O FT PC6 I2S2_MCK/ TIM3_CH1
E10 38 64 PC7 I/O FT PC7 I2S3_MCK TIM3_CH2
F9 39 65 PC8 I/O FT PC8 TIM3_CH3
E9 40 66 PC9 I/O FT PC9 TIM3_CH4
D9 4 1 67 PA 8 I/O F T PA 8
USART1_CK/OTG_FS_SOF /
TIM1_CH1
(8)
/MCO
C9 4 2 68 PA 9 I/O F T PA 9
USART1_TX
(7)
/ TIM1_CH2
(7)
/
OTG_FS_VBUS
D10 43 69 PA10 I/O FT PA10
USART1_RX
(7)
/
TIM1_CH3
(7)
/OTG_FS_ID
C10 44 70 PA11 I/O FT PA11
USART1_CTS / CAN1_RX /
TIM1_CH4
(7)
/OTG_FS_DM
B10 45 71 PA12 I/O FT PA12
USART1_RTS / OTG_FS_DP /
CAN1_TX
(7)
/ TIM1_ETR
(7)
A10 46 72 PA13 I/O FT JTMS-SWDIO
PA13
F8 - 73 Not connected
E6 47 74
V
SS_2
SV
SS_2
F6 48 75
V
DD_2
SV
DD_2
A9 49 76
PA14 I/O FT JTCK-SWCLK PA14
A8 50 77
PA15 I/O FT JTDI SPI3_NSS / I2S3_WS
TIM2_CH1_ETR
/ PA15
SPI1_NSS
B9 51 78
PC10 I/O FT PC10 UART4_TX
USART3_TX/
SPI3_SCK/I2S3_CK
B8 52 79
PC11 I/O FT PC11 UART4_RX
USART3_RX/
SPI3_MISO
C8 53 80
PC12 I/O FT PC12 UART5_TX
USART3_CK/
SPI3_MOSI/I2S3_SD
--81
PD0 I/O FT PD0 OSC_IN
(9)
/
CAN1_RX
--82
PD1 I/O FT PD1 OSC_OUT
(9)
/
CAN1_TX
B7 54 83
PD2 I/O FT PD2 TIM3_ETR / UART5_RX
C7 - 84
PD3 I/O FT PD3
USART2_CTS
D7 - 85
PD4 I/O FT PD4
USART2_RTS
B6 - 86
PD5 I/O FT PD5
USART2_TX
C6 - 87
PD6 I/O FT PD6
USART2_RX
D6 - 88
PD7 I/O FT PD7
USART2_CK
Table 5. Pin definitions (continued)
Pins
Pin name
Type
(1)
I / O Level
(2)
Main
function
(3)
(after reset)
Alternate functions
(4)
BGA100
LQFP64
LQFP100
Default Remap
