Pinouts and pin description STM32F105xx, STM32F107xx
26/104 Doc ID 15274 Rev 6
Table 5. Pin definitions
Pins
Pin name
Type
(1)
I / O Level
(2)
Main
function
(3)
(after reset)
Alternate functions
(4)
BGA100
LQFP64
LQFP100
Default Remap
A3 - 1 PE2 I/O
FT
PE2 TRACECK
B3 - 2 PE3 I/O
FT
PE3 TRACED0
C3 - 3 PE4 I/O
FT
PE4 TRACED1
D3 - 4 PE5 I/O
FT
PE5 TRACED2
E3 - 5 PE6 I/O
FT
PE6 TRACED3
B2 1 6 V
BAT
SV
BAT
A2 2 7
PC13-TAMPER-
RTC
(5)
I/O PC13
(6)
TAMPER-RTC
A1 3 8
PC14-
OSC32_IN
(5)
I/O PC14
(6)
OSC32_IN
B1 4 9
PC15-
OSC32_OUT
(5)
I/O PC15
(6)
OSC32_OUT
C2 - 10 V
SS_5
SV
SS_5
D2 - 11 V
DD_5
SV
DD_5
C1 5 12 OSC_IN I OSC_IN
D1 6 13 OSC_OUT O OSC_OUT
E1 7 14 NRST I/O NRST
F1 8 15 PC0 I/O PC0 ADC12_IN10
F2 9 16 PC1 I/O PC1
ADC12_IN11/ ETH_MII_MDC/
ETH_RMII_MDC
E2 10 17 PC2 I/O PC2 ADC12_IN12/ ETH_MII_TXD2
F3 11 18 PC3 I/O PC3
ADC12_IN13/
ETH_MII_TX_CLK
G1 12 19 V
SSA
SV
SSA
H1 - 20 V
REF-
SV
REF-
J1 - 21 V
REF+
SV
REF+
K1 13 22 V
DDA
SV
DDA
G2 14 23 PA0-WKUP I/O PA0
WKUP/USART2_CTS
(7)
ADC12_IN0/TIM2_CH1_ETR
TIM5_CH1/
ETH_MII_CRS_WKUP
H2 1 5 24 PA 1 I/O PA 1
USART2_RTS
(7)
/ ADC12_IN1/
TIM5_CH2 /TIM2_CH2
(7)
/
ETH_MII_RX_CLK/
ETH_RMII_REF_CLK
