Description STM32F105xx, STM32F107xx
10/104 Doc ID 15274 Rev 6
2.1 Device overview
Figure 1 shows the general block diagram of the device family.
Table 2. STM32F105xx and STM32F107xx features and peripheral counts
Peripherals
(1)
STM32F105Rx STM32F107Rx STM32F105Vx STM32F107Vx
Flash memory in Kbytes 64 128 256 128 256 64 128 256 128 256
SRAM in Kbytes 64
Package LQFP64
LQFP
100
LQFP100,
BGA100
LQFP100
Ethernet No Yes No Yes
Timers
General-purpose 4
Advanced-control 1
Basic 2
Communication
interfaces
SPI(I
2
S)
(2)
3(2) 3(2) 3(2) 3(2)
I
2
C2121
USART 5
USB OTG FS Yes
CAN 2
GPIOs 51 80
12-bit ADC
Number of channels
2
16
12-bit DAC
Number of channels
2
2
CPU frequency 72 MHz
Operating voltage 2.0 to 3.6 V
Operating temperatures
Ambient temperatures: –40 to +85 °C /–40 to +105 °C
Junction temperature: –40 to + 125 °C
1. Please refer to Table 5: Pin definitions for peripheral availability when the I/O pins are shared by the peripherals required by
the application.
2. The SPI2 and SPI3 interfaces give the flexibility to work in either the SPI mode or the I
2
S audio mode.
