User's Manual

MS 170, MS 170 C, MS 180, MS 180 C
English
51
Chain sprocket
To ensure compliance with the kickback
properties required in Section 5.11 of
ANSI B 175.1-2000, only use
replacement chains that, when used
with this specific powerhead, comply
with Section 5.11 of the ANSI standard
or are classed as "low kickback" chains
according to ANSI B 175.1-2000.
Please ask your STIHL dealer for the
latest recommendations on new
bar/chain combinations developed after
publication of this instruction manual.
Cutting Attachment (MS 180 C)
Recommended cutting attachments
complying with Section 5.11 of ANSI B
175.1-2000.
Observe notes on ANSI B 175.1-2000
and definition of "low kickback chain" in
chapter on "Safety Precautions and
Working Techniques".
Rollomatic E guide bars
3/8" Picco chain
Chain sprocket
To ensure compliance with the kickback
properties required in Section 5.11 of
ANSI B 175.1-2000, only use
replacement chains that, when used
with this specific powerhead, comply
with Section 5.11 of the ANSI standard
or are classed as "low kickback" chains
according to ANSI B 175.1-2000.
Please ask your STIHL dealer for the
latest recommendations on new
bar/chain combinations developed after
publication of this instruction manual.
Contact your STIHL dealer for
information regarding special
accessories that may be available for
your product.
Chain scabbard
If you use guide bars of different lengths
on the saw, the length of the chain
scabbard must be matched to the guide
bar to help reduce the risk of injury.
If the chain scabbard does not cover the
full length of the guide bar, a suitable
chain scabbard or a scabbard extension
is necessary.
Depending on the model, the scabbard
extension either comes standard with
the saw or is available as a special
accessory.
Fitting the chain scabbard extension
onto the scabbard
The scabbard extension has two square
cut-outs (1) that fit onto one of several
sets of locking tabs (2, 3, 4) located on
the scabbard. Each set of locking tabs is
marked with the lenght of the bar to
which they correspond, given in
centimeters on one tab and in inches on
the other.
6--tooth for 3/8" (spur sprocket)
Reduced kickback STIHL guide bar
(with green label)
Cutting lengths: 12, 14, 16 in. (30,
35, 40 cm)
Pitch: 3/8" P (9.32 mm)
Groove width: 0.050 in. (1.3 mm)
Low kickback STIHL saw chain (with
green label)
Picco Micro Comfort 3 (63 PMC3)
Pitch: 3/8" P (9.32 mm)
Drive link gauge: 0.050 in. (1.3 mm)
6--tooth for 3/8" (spur sprocket)
Special Accessories
