Instruction Manual

SG 20
English
10
Before Spraying
N Oil the pump piston (1).
N Oil the spray gun’s valve plunger
(2).
N Put the unit on your back.
N Operate the hand lever (2) slowly
and steadily with the gun closed – 8
to 10 strokes are required to build
up pressure.
Spraying
N Pull the spray gun's trigger (1).
N Operate the hand lever 3 to 6 times
per minute to maintain a uniform
spray pressure.
N Rotate the nozzle (2) to adjust the
spray pattern.
For continuous operation:
N Pull the trigger.
N Engage the U-clip (3) in direction of
the arrow – the trigger is locked.
N Empty the tank in a well-ventilated
location.
N Dispose of any residual spray
solution in accordance with
environmental requirements –
follow instructions of the chemical
manufacturer.
N Rinse the tank with clean water.
N Fill the tank with about 1 1/4 gal.
(5 liters) of clean water, pump and
spray until the tank and hose
system are empty and no longer
under pressure. Do not store the
sprayer under pressure or with
spray solution in the tank.
N After finishing work, clean the
filter (1) in the spray gun.
N Allow the unit to dry with the cap
removed.
N Store the unit in a dry place
protected from frost.
Spraying
2
0000-GXX-8700
Storing the Machine
