User Manual

0478 111 9937 D - EN
54
RM 756.0 GC, RM 756.0 GS,
RM 756.0 YC
– Measured sound power level:
97.4 dB(A)
– Guaranteed sound power level:
98 dB(A)
The technical documents are stored at
STIHL Tirol GmbH.
The year of manufacture and machine
number are indicated on the lawn mower.
Langkampfen, 02.11.2021
STIHL Tirol GmbH
p.p.
Matthias Fleischer, Vice President Product
Development
p.p.
Sven Zimmermann, Director Quality
Management
17. Technical specifications
RM 756.0 GC/RM 756.0 GS/RM 756.0 Y
C/RM 756.0 YS
Serial number 6378
Engine, design 4-stroke com-
bustion engine
Manufacturer Kawasaki
Type
FJ 180 V KAI
OHV
Displacement 179 ccm
Housing material Die-cast
magnesium
Nominal output at
nominal speed
2,9 - 2800
kW - rpm
Fuel tank 3 l
Starter Rope start
Cutting tool Cutter bar
Cutting width 54 cm
Cutter bar speed 2800 rpm
Cutter bar drive BBC
Blade fastening
screw tightening
torque 60 - 65 Nm
Wheel diameter
(front) 207 mm
Wheel diameter
(rear) 232 mm
Grass catcher box
capacity 80 l
Cutting height 25 - 90 mm
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
2,40 m/sec
2
Uncertainty K
hw
1,20 m/sec
2
Measurement in accordance with EN ISO
5395-2, EN 20643
In accordance with
2000/14/EC/S.I.
2001/1701:
Guaranteed sound
power level L
WAd
98 dB(A)
Uncertainty K
WA
1 dB(A)
In accordance with
EN ISO 5395-2:
Sound pressure level
at workplace L
pA
86 dB(A)
Uncertainty K
pA
2 dB(A)
L/W/H 176/59/116 cm
RM 756.0 GC
Self-propulsion, rear
wheels 3 V (3-speed)
Weight 60 kg
RM 756.0 GS
Self-propulsion, rear
wheels 3 V (3-speed)
Weight 60 kg
RM 756.0 YC
Self-propulsion, rear
wheels
Hydrostatic
gearbox, contin-
uously variable
Weight 61 kg
RM 756.0 YS
Self-propulsion, rear
wheels
Hydrostatic
gearbox, contin-
uously variable
Weight 60 kg
RM 756.0 GC/RM 756.0 GS/RM 756.0 Y
C/RM 756.0 YS
