Adjusting the cable
● Tighten cable (1) using two nuts (2, 3)
on the underside of the handlebar so
that all three gears can be correctly
engaged.
Adjusting the self-propulsion
cable
RM 756 GC, RM 756 GS
Maintenance interval:
As required
Adjustment of the cable is necessary
– if self-propulsion is not activated when
the self-propulsion lever is operated.
– if self-propulsion is permanently
engaged. This means that the lawn
mower automatically begins to move
when the recoil starter rope is pulled,
despite the self-propulsion lever not
being actuated.
Checking the cable tension:
1. Engage 3rd gear and pull the recoil
starter rope – the lawn mower is not
driven.
2. Pull the self-propulsion lever to the
handlebar and hold, pull the recoil
starter rope – the lawn mower is driven.
Adjusting the cable:
● Tighten cable (1) using two nuts (2, 3)
on the underside of the handlebar so
that self-propulsion is activated at about
half the travel of the self-propulsion
lever.
11.10 Storage and periods of
inoperation (winter break)
Store the machine in a dry, locked, dust-
free place. Make sure that it is out of the
reach of children.
Any faults must be remedied prior to
storage. The machine must always be in a
safe operating condition.
Empty the fuel tank and carburettor prior to
storage (e.g. by running empty).
Also note the following points when storing
the machine for long periods (winter
break):
● Clean all external parts of the machine
with care.
● Thoroughly lubricate/grease all moving
parts.
● Unscrew the spark plug (see engine
instruction manual) and pour approx.
3 cm³ of engine oil into the engine via
the spark plug hole. Turn the engine
several times with the spark plug
removed (pull the recoil starter rope).
● Screw the spark plug back in (see
engine instruction manual).
● Perform an oil change (see engine
instruction manual).
12.1 Securing the machine
(lashing)
Only transport the machine on all
four wheels, on a clean, level load floor.
● Secure the machine against slipping
using suitable fastening materials.
Attach ropes or straps to lower
handlebar (1) and bumper (2).
12.2 Lifting or carrying the machine
The lawn mower must always be lifted and
carried by two people.
All models:
● Hold and lift the lawn mower by
bumper (1) and handlebar (2).
RM 756 GC, RM 756 YC –
Additional carrying method:
● Pull carrying handle (3) out from
the lower handlebar as far as it will go.
● Right:
Hold and lift the lawn mower by
bumper (1) and handlebar (2).
Left:
Hold and lift the lawn mower by
bumper (1) and carrying handle (3).
Risk of injury!
The self-propulsion cable must be
correctly adjusted before the
machine is operated.
27
Fire hazard!
Keep the spark plug socket away
from the spark plug hole due to the
danger of ignition.
12. Transport
Risk of injury!
Before transporting, carefully read
and observe the section "For your
safety", in particular the
"Transporting the machine" section.
(Ö 4.4)
