Instruction Manual

1 Introduction............................................... 20
2 Guide to Using this Manual.......................20
3 Overview................................................... 21
4 Safety Precautions....................................21
5 Preparing the Lawn Scarifier for Operation
.................................................................. 26
6 Assembling the Lawn Scarifier..................26
7 Adjusting the Lawn Scarifier for the User..27
8 Connecting the Lawn Scarifier to the Mains
.................................................................. 28
9 Switching the Lawn Scarifier On and Off.. 28
10 Checking the Lawn Scarifier..................... 28
11 Working with the Lawn Scarifier................29
12 After Finishing Work..................................30
13 Transporting..............................................30
14 Storing.......................................................31
15 Cleaning....................................................31
16 Maintenance............................................. 32
17 Repairing...................................................32
18 Troubleshooting........................................ 32
19 Specifications............................................33
20 Spare Parts and Accessories....................34
21 Disposal.................................................... 34
22 EC Declaration of Conformity................... 34
23 Safety Information for Lawn Scarifiers...... 35
1 Introduction
Dear Customer,
Thank you for choosing STIHL. We develop and
manufacture our quality products to meet our
customers’ requirements. The products are
designed for reliability even under extreme con‐
ditions.
STIHL also stands for premium service quality.
Our dealers guarantee competent advice and
instruction as well as comprehensive service
support.
STIHL expressly commit themselves to a sus‐
tainable and responsible handling of natural
resources. This user manual is intended to help
you use your STIHL product safely and in an
environmentally friendly manner over a long
service life.
We thank you for your confidence in us and hope
you will enjoy working with your STIHL product.
Dr. Nikolas Stihl
IMPORTANT! READ BEFORE USING AND
KEEP IN A SAFE PLACE FOR REFERENCE.
2 Guide to Using this Manual
2.1 Applicable Documentation
Local safety regulations apply.
2.2 Warning Notices in Text
DANGER
■ This notice refers to risks which result in seri‐
ous or fatal injury.
► Serious or fatal injuries can be avoided by
taking the precautions mentioned.
WARNING
■ This notice refers to risks which can result in
serious or fatal injury.
► Serious or fatal injuries can be avoided by
taking the precautions mentioned.
NOTICE
■ This notice refers to risks which can result in
damage to property.
► Damage to property can be avoided by tak‐
ing the precautions mentioned.
2.3 Symbols in Text
This symbol refers to a chapter in this
instruction manual.
3 Overview
3.1 Lawn Scarifier
10
11
9
1
2
4
7
5
#
3
6
8
4
0000-GXX-B364-A0
