Operation Manual

KM 111 R, KM 131, KM 131 R
English
7
To reduce the risk of fire and damage to
hearing, do not operate your machine if
the muffler is damaged or missing. –
Do not touch a hot muffler since burn
injury will result.
Vibration behavior is influenced by the
condition of the AV elements – check the
AV elements at regular intervals.
The following STIHL KombiTools may
be mounted on the KombiEngine:
A barrier bar is supplied with the
machine. Attach the barrier bar to the
loop handle.
N Insert square nuts (1) in the barrier
bar (2) – the holes must line up
Approved KombiTools
KombiTool
1)
for KombiEngines with loop handle:
The barrier bar supplied with the
loop handle must be used – see
also "Mounting the Loop Handle"
2)
Not approved for KombiEngines
with bike handle
3)
Limited suitability for KombiEngines
with bike handle
4)
Not approved for KM 131 or
KM 131 R
Application
FS-KM Brushcutter with
mowing head
FS-KM
1)
Brushcutter with
grass cutting blade
FSB-KM
3) 4)
Brushcutter with
mowing head
HL-KM 145°
3)
Long reach hedge
trimmer, adjustable
HL-KM 0°
2)
Long reach hedge
trimmer
FH-KM 145° Power scythe
BG-KM
3)
Blower
HT-KM
2)
Pole pruners
BF-KM Cultivator with pick
tines
FCB-KM
3)
Edger
FCS-KM
3)
Edger
SP-KM
2) 4)
Special harvester
KB-KM
2)
Bristle brush
KW-KM
2)
PowerSweep
Mounting the Loop Handle
2
002BA098 KN
1
1
