Operation Manual

KM 111 R, KM 131, KM 131 R
English
13
Version with Bike Handle
1 Throttle trigger lockout
2 Throttle trigger
3 Stop switch with Run and Stop
positions. Depress the stop switch
(…) to switch off the ignition – see
"Function of stop switch and ignition
system".
Function of stop switch and ignition
system
The ignition is switched off and the
engine stopped when the stop switch is
pressed. The stop switch returns
automatically to the Run position when it
is released: The ignition is switched on
again after the engine stops – the engine
is then ready to start.
Starting the Engine
N Press the manual fuel pump
bulb (9) at least five times – even if
the bulb is already filled with fuel.
N Press in the choke knob (8) and turn
it to the position that suits the engine
temperature:
The choke knob must engage in
position.
Cranking
N Place the power tool on the ground
so that it rests on the machine
support: Check that the working tool
is not touching the ground or any
other obstacles – see also "Starting
/ Stopping the Engine" in the
KombiTool instruction manual.
N Make sure you have a safe and
secure footing.
N Hold the unit with your left hand and
press it down firmly – your thumb
should be under the fan housing.
NOTICE
Do not stand or kneel on the drive tube.
3
1
2
0000-GXX-0494-A0
g if the engine is cold
< for warm start – also use this posi-
tion if the engine has been running
but is still cold.
0000-GXX-0478-A0
0000-GXX-1316-A0
0000-GXX-1319-A0
