0478 201 8313 B - EN
26
12.2 Pulling or pushing the garden
shredder
● Hold the garden shredder at the upper
chute (1) and tilt to the rear.
● The garden shredder can be pulled or
pushed slowly (walking pace).
12.3 Lifting or carrying the garden
shredder
● 1st person: Hold the garden shredder at
the handles on the upper chute (1).
● 2nd person: Hold the garden shredder
at the strip of the ejection chute
extension (2).
● Lift the garden shredder
simultaneously.
12.4 Transporting the garden shredder
on a load floor
● Secure the machine against slipping
using suitable fastening materials.
Attach ropes or straps to wheel
carrier (1) or feed chute (2).
At least two persons are always
required to lift and carry the
machine.
Wear suitable protective clothing;
the lower arms and upper part of
the body must be fully covered.
