EN
17
0478 201 8313 B - EN
Closing the discharge flap:
● For transport or space-saving storage,
lift tab (2) slightly and fold away
discharge flap (1) downwards.
7.4 Attaching the upper chute
● Place upper chute (S) with symbol (1)
facing forwards on lower chute (3) in
the direction of closure screws (2).
● Screw in screws (T) in the sequence
shown (1 2 3 4).
7.5 Mounting the cable clip
● Press electric cable (1) into the
designated recesses in cable clip (2) as
shown.
8.1 What material can be processed?
– Feeding the garden shredder. (Ö 8.8)
GHE 150, GHE 250 S:
Tree and hedge cuttings as well as thick
branch material with side shoots.
The chute can only be installed by a
specialist dealer using special
tools. STIHL recommends STIHL
specialist dealers.
We recommend following the
described installation sequence to
prevent the splash guard slipping
off when screwing in the screws.
8. Notes on working with the
machine
