Instruction Manual

FS 410 C-M K, FS 460 C-M K, FS 490 C-M K
English
38
Weight
Overall length
Features
Noise and Vibration Data
Noise and vibration data measurements
on FS units include idling and rated
maximum speed with the same duration
of exposure.
For further details on compliance with
Vibration Directive 2002/44/EC see
www.stihl.com/vib.
Sound pressure level L
p
to ISO 22868
Sound power level L
w
to ISO 22868
Vibration measurement a
hv,eq
to
ISO 22867
The K
-
factor in accordance with
Directive 2006/42/EC is 2.0 dB(A) for
the sound pressure level and sound
power level; the K
-
factor in accordance
with Directive 2006/42/EC is 2.0 m/s
2
for the vibration level.
REACH
REACH is an EC regulation and stands
for the Registration, Evaluation,
Authorisation and Restriction of
Chemical substances.
For information on compliance with the
REACH regulation (EC) No. 1907/2006
see www.stihl.com/reach.
Exhaust Emissions
The CO
2
value measured in the EU type
approval procedure is specified at
www.stihl.com/co2.
The measured CO
2
value was
determined on a representative engine
in accordance with a standardized test
procedure under laboratory conditions
and does not represent either an explicit
or implied guarantee of the performance
of a specific engine.
The applicable exhaust emission
requirements are fulfilled by the
intended usage and maintenance
described in this instruction manual. The
type approval expires if the engine is
modified in any way.
Dry, without cutting attachment and
deflector
FS 410 C-EM K: 8.4 kg
FS 460 C-EM K: 8.4 kg
FS 460 C-EM KW: 8.5 kg
FS 490 C-EM K: 9.2 kg
FS 490 C-EM KW: 9.4 kg
without cutting attachment
FS 410 C-EM K: 1675 mm
FS 460 C-EM K: 1675 mm
FS 460 C-EM KW: 1675 mm
FS 490 C-EM K: 1680 mm
FS 490 C-EM KW: 1680 mm
C Convenience features
E ErgoStart
M M-Tronic
K Short drive tube
W Handle heating
Z Spark arresting screen
with metal cutting
attachment
FS 410 C-EM K: 100 dB(A)
FS 460 C-EM K: 101 dB(A)
FS 460 C-EM KW: 102 dB(A)
FS 490 C-EM K: 102 dB(A)
FS 490 C-EM KW: 102 dB(A)
with metal cutting
attachment
FS 410 C-EM K: 112 dB(A)
FS 460 C-EM K: 113 dB(A)
FS 460 C-EM KW: 114 dB(A)
FS 490 C-EM K: 115 dB(A)
FS 490 C-EM KW: 116 dB(A)
with metal cutting
attachment
Handle,
left
Handle,
right
FS 410 C-EM K: 2.4 m/s
2
2.0 m/s
2
FS 460 C-EM K: 2.4 m/s
2
2.0 m/s
2
FS 460 C-EM KW: 2.4 m/s
2
2.0 m/s
2
FS 490 C-EM K: 2.8 m/s
2
2.8 m/s
2
FS 490 C-EM KW: 2.8 m/s
2
2.8 m/s
2
