Instruction Manual

FS 410 C-M K, FS 460 C-M K, FS 490 C-M K
English
37
1 Metal mowing attachment
2 Deflector for metal mowing
attachments only
3 Circular saw blade
4 Limit stop for circular saw blades
only
Engine
Single cylinder two-stroke engine
FS 410 C
FS 460 C
FS 490 C
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
002BA545 KN
2
1
4
002BA546 KN
3
Specifications
Displacement: 41.6 cc
Bore: 42 mm
Stroke: 30 mm
Engine power to
ISO 8893:
2.0 kW (2.7 bhp)
at 9,000 rpm
Idle speed: 2,700 rpm
Cut-off speed (rated): 12,300 rpm
Max. output shaft
speed (cutting
attachment): 10,130 rpm
Displacement: 45.6 cc
Bore: 44 mm
Stroke: 30 mm
Engine power to
ISO 8893:
2.2 kW (3 bhp)
at 9,500 rpm
Idle speed: 2,700 rpm
Cut-off speed (rated): 12,300 rpm
Max. output shaft
speed (cutting
attachment): 10,130 rpm
Displacement: 51.6 cc
Bore: 44.7 mm
Stroke: 32.9 mm
Engine power to
ISO 8893:
2.4 kW (3.3 HP)
at 9,500 rpm
Idle speed: 2,500 rpm
Cut-off speed (rated): 12,300 rpm
Max. output shaft
speed (cutting
attachment): 10,130 rpm
FS 410 C, FS 460 C
Spark plug (resistor
type):
NGK CMR6H
Bosch USR4AC
Electrode gap: 0.5 mm
FS 490 C
Spark plug (resistor
type):
NGK BPMR7A
Electrode gap: 0.5 mm
Fuel tank capacity:
FS 410 C: 750 cc (0.75 l)
FS 460 C: 750 cc (0.75 l)
FS 490 C: 990 cc (0.99 l)
