Instruction Manual

FS 410 C-M K, FS 460 C-M K, FS 490 C-M K
English
23
Throwing Off Machine
WARNING
The machine must be quickly thrown off
in the event of imminent danger.
Practice removing and putting down the
power tool as you would in an
emergency. To avoid damage, do not
throw the power tool to the ground when
practicing.
Controls
1 Throttle trigger lockout
2 Throttle trigger
3 Stop switch with Run and Stop
positions. Press the momentary
contact stop switch to switch off the
ignition.
Function of stop switch and ignition
system
The stop switch is normally in the Run
position, i.e. when it is not depressed:
The ignition is switched on – the engine
is ready to start. Operate the stop switch
to switch off the ignition. The ignition is
switched on again automatically after
the engine stops.
Symbols on choke knob
Run position F – a hot engine is started
in this position or the engine runs in this
position.
Start position } – a cold engine is
started in this position.
Starting the Engine
N Press the manual fuel pump
bulb (4) at least five times – even if
the bulb is filled with fuel.
Starting / Stopping the
Engine
1
002BA484 KN
2
3
FS 490
0000-GXX-0839-A0
FS 460
FS 410, 460
4
0000-GXX-0840-A0
FS 410, 460
4
2709BA015 KN
FS 490
