Instruction Manual

0458-820-8621-A
26
English 22 Specifications
22.3 STIHL AL 500
– Mains voltage: 120 V
– Rated current: 4.8 A
– Frequency: 60 Hz
– Charging current: 12 A
– Rated power: 570 W
– Insulation: Class II (Double Insulation)
– For optimum performance, STIHL recommends operating
the charger within an ambient temperature range of: 41 °F
to 104 °F (5 °C to 40 °C)
22.4 Symbols on the Backpack Battery
22.5 Engineering Improvements
STIHL's philosophy is to continually improve all of its
products. As a result, engineering changes and
improvements are made from time to time. Therefore, some
changes, modifications and improvements may not be
covered in this manual. If the operating characteristics or the
appearance of your machine differs from those described in
this manual, please contact your STIHL dealer or the STIHL
distributor in your area for assistance.
22.6 FCC 15 Compliance Statement
This device contains a transmitter (FCC ID: 2ALP8ARL) that
complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
– this device may not cause harmful interference.
– this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
– reorient or relocate the receiving antenna,
Symbol Explanation
VVolt
Ah Ampere hour
Wh Watt hour
The battery is equipped with Bluetooth
®
and can
be connected with the STIHL connected App.
Direct current
STIHL products must not be disposed of in the
household trash, but only in accordance with local,
state and federal laws and regulations and as
provided in this manual, @ 24.
Number of cells and stored energy according to cell
manufacturer's specification. Usable energy will be
less.
Certification/listing mark of CSA
The RBRC seal indicates that STIHL has prepaid for
battery recycling
This symbol indicates that this is an recyclable
lithium-ion battery
