Specification Sheet

Features
•
Compression molded from our exclusive solid Vikrell
®
material
•
Bath and integral apron eliminates installation step
•
Durable high-gloss finish
•
Tongue-and-groove 4-piece modular design allows for
easy ″snap together″ installation
•
Caulkless seam installation
•
10-year consumer/3-year commercial limited warranty
•
2″ (51 mm) wainscot/tile ledge
•
18″ (457 mm) bath depth (floor to top of threshold)
•
Includes age-in-place factory installed backers for
later grab bar installation
•
60-1/4″ (1530 mm) x 33-1/4″ (845 mm) x 76-1/4″
(1937 mm) complete unit rough-in dimensions include
flange
•
60″ (1524 mm) x 32″ (813 mm) x 75″ (1905 mm)
complete unit finished dimensions
Codes/Standards Applicable
Specified model meets or exceeds the following:
•
CSA B45.5/IAPMO Z124
•
ASTM E162
•
ASTM E662
•
HUD, UM Bulletin 73A
•
NAHB Research Foundation, Inc.
32″ BATH AND MEDLEYTM WALL
SURROUND WITH BACKER BOARDS
71320116
ALSO 71320126
Colors/Finishes
•
0: White
•
Other: Refer to Price Book for additional colors/finishes
Specified Model
Model Complete Unit Description Colors/Finishes
71320116 32″ bath and wall surround with backer boards, left drain ❑ 0 ❑ Other_____
71320126 32″ bath and wall surround with backer boards, right drain
(shown)
❑ 0 ❑ Other_____
ENSEMBLETM
Page 1 of 2
1214194-4-
A
For more information
visit SterlingPlumbing.com
or call 1-800-STERLING
