Dimensions Guide

No image available.
Notes
Technical Information
Measure your actual product for rough-in details.
All product dimensions are nominal.
Install this product according to the installation
instructions.
3-Wall AlcoveInstallation:
55-1/2" (1410 mm)Door height required:
Install this product according to the installation
guide.
57-11/16" (1465 mm)Door width required:
Studs should be positioned roughly as shown.
Double studding is recommended for pivot shower
door installations.
Attach grab bars at the specified backer board
locations only.
USA/Canada: 1-800-STERLING (1-800-783-7546)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.sterlingplumbing.com.
11-13-2015 04:37
60" x 32" Curve Wall Set with Backer Boards
71224106
