PARTS LIST AND DRAWINGS
SECTION 8-2
Parts Identification Drawing No. CI044035
MODEL 2042 2050 2062
ITEM # Qty. Qty. Qty. MATERIAL
1 1 1 1 LH end plate
2 1 1 1 RH end plate
3 1 1 1 Down stroke knife block
4 1 1 1 Up stroke knife block
5 2 2 2 Up stroke knife clamp
6 1 1 1 LH down stroke knife shield
7 1 1 1 RH down stroke knife shield
8 1 1 1 Upper chamber
9 20 - 28 M20 bed knife washers
10 20 - 28 M20 Hex HD. screw Gr. 10.9
11 44 44 44 Plain washer M20
12 44 44 44 Lock washer M20
13 26 26 26 M20 Hex HD. screw Gr. 8.8
14 12 12 12 Dowel pin
15 1 1 1 Pivot pin
16 1 1 1 Pivot pin
17 2 2 2 Retainer bar
18 2 2 2 M8 Hex HD. screw Gr. 8.8
19 4 - 6 Cradle wedge assembly
20 12 - 18 M8 Hex HD. screw Gr. 8.8
21 12 - 18 M8 hex nut
22 3 - 4 Eye bolt M24 THD
23 3 - 4 Handle
24 3 - 4 Flat washer
25 3 - 4 Dowel pin 20 MM
26 6 - 8 Dowel pin 40 MM
27 2 2 2 Bearing housing
28 1 1 1 Cradle assembly
29 1 1 1 Bearing cap
*NOTES: Din No. 961-10
When ordering spare parts, please have the model and serial number on hand.
Please call one of the following locations:
STERLING -So. Attleboro, MA - - 508-399-3000
West Coast Service Center-Ontario, CA - - 909-390-8140/8141
Central Service Center-Kansas City, KA - - 913-780-0215
