PARTS LIST AND DRAWINGS
SECTION 8-1
Recommended Spare Parts
2000 SERIES GARNULATOR
TABLE 1: Recommended Spare Parts
Model 2042 2050 2062
Item Qty. Qty. Qty. Material
Rotor Knife (Depending on rotor) 6/10 6/10 6/10 HCHC
Bed Knife 4 4 4 HCHC
Rotor Knife Screw (See Copy) 24/48 - 36/60 *Property class 10.9-
M20 x 50 MM
Bed Knife Washer 20 - 28 *Property class 10.9-
M20 x 90 MM
Screen 20 - 28 Hardened
Rotor Bearing 2 2 3 Mild Steel -
3/8” Diameter hole- standard
Drive Belt 2 2 2 130 MM Bore
6 - - 5VX1500 –
Quantity for standard 75 hp drive
- 8 - 5VX1500 –
Quantity for standard 100 hp drive
- - 8 5VX1500 –
Quantity for standard 100 hp drive
Adjusting Screw – Bed Knife 8 8 8 Push Screws
