INSTALLATION
SECTION 3-6
ALTERNATE TEST FOR THE INTEROCK SWITCHES
(Continued from previous page)
After the test or repair, engage the screen cradle interlock actuator screw.
If necessary, unlock and turn on the power.
Push the start button to start the granulator.
Retract the cutting chamber interlock actuator screw by turning it counterclockwise. The granulator
should stop after several turns.
If the machine continues to run, TURN OFF AND LOCK THE POWER per
OSHA 1910.147 or ANSI Z244.1-1982 (Lock-out/Tag-out of energy sources).
Have an electrician check the interlock switch on the cutting chamber to correct the malfunction.
After the test or repair, if necessary, engage the cutting chamber interlock actuator screw.
TEST THE ZERO SENSOR (Optional) - STANDARD with 50” & 62” Wide Machine
Depress the button to start the granulator.
When the machine reaches full speed, depress the stop button to stop the granulator.
Release the cutting chamber hold-down clamps using the procedures in Section 6 entitled Cutting
Chamber Access.
While the rotor is still turning, actuate the hopper opening hydraulic system console by turning the
CC/Hopper selector switch to the RAISE position.
The hydraulic system should not operate until the rotor has come to a complete stop.
If the hydraulic system operates before the rotor stops, TURN OFF AND LOCKOUT THE
POWER per OHSA 1910.147 or ANSI Z244.1-1982 (Lock-out/Tag-out Energy Sources).
Have a mechanic and electrician check the speed sensor.
LUBRICATION
The machine is pre-lubricated except for the motor. For motor lubrication, check the tag supplied by the
motor manufacturer.
After the 2000-Series Granulator has been in service for some time, the main bearings should be periodically
lubricated. Refer to Section 6, Maintenance, for further information.
