Instruction Manual

REVISION 9/04 BJF
13
SAFETY
SECTION 1-3
Safety Symbols & Plates
ROTATING MACHINERY SAFETY PLATE
(One located on the machine guard on the left side of the machine, one on the
screen cradle on the front panel, to the right of the machine center.)
Avoid personal injury by making sure that the rotor is stopped and the power is
disconnected and locked out before removing a machine guard. A motion
sensor monitors the rotor and disables the jackscrew motors if there is rotor
movement. If you see the rotor spinning after opening the machine,
immediately shut down and call for service.
OPENING HOPPER SAFETY PLATE
(Located on center at the lower, front side of the hopper)
Take the time for safety by disconnecting and locking out the
power before opening the hopper. Work carefully and beware of all hazards
with the hopper open and the knives exposed.
ROTATING KNIVES SAFETY PLATE (One located near the discharge
port and one located near the vent port on each side of the machine.)
Never reach into the vent or discharge areas without shutting down the machine
and locking out the power. Wear protective gloves whenever you work around
the rotor knives and do not open the access doors to them until you are certain
that the rotor has stopped and you have disconnected and locked out the power.
To clear a jam, refer to the topic entitled Safely Clearing a Jam later in this
section.
